6243/44 DC Voltage Current Source/Monitor Operation Manual
A.3 Execution Time
A-5
A.3 Execution Time
A.3.1 GPIB Remote Execution Time (Nominal Values)
Computer: Fujitsu FMV-6266T6, Windows 95
GPIB hardware: AT-GPIB/TNT (PnP) manufactured by NATIONAL INSTRUMENTS
Used module: Niglobal.bas, Vbib-32.bas (supplied with AT-GPIB/TNT (PnP))
Applied language: Visual Basic 5
(1) Program code execution time
Time from the program code reception to the time when the next program code reception becomes
ready.
Item Program code Condition
Execution
time
Unit: ms
Operate /
Standby
Operate E Source mode: DC or Pulse 120
Source mode: Sweep 310
Standby H 80
Source function VF, IF Source mode:
DC or Pulse
operation, and
Hold mode
With a current
range change
18
V3 to V6, I-1 to I4 Without a current
range change
38
Source range change V3 to V6 12
I-1 to I4 33
Voltage
source /
Voltage
limiter*
Source value
Limiter value
Pulse value
Base value
Bias value
D<data>, DB<data>, SB<data>
Without unit
Operate and
HOLD mode
Without polarity
change
11 to 17
With polarity
change
16 to 22
D<data>unit, DB<data>unit,
SB<data>unit
With unit
Without polarity
change
13 to 21
With polarity
change
17 to 26
With range change 17 to 26
