6243/44 DC Voltage Current Source/Monitor Operation Manual
2.3.1 Measuring a Diode
2-35
34. Press the OPERATE key.
The status becomes Standby.
35. Connect the HI OUTPUT (red) lead to the diode’s anode.
36. Press the OPERATE key.
The measured result of the diode’s reverse leak current (IR) appears.
NOTE: For 6244, the current measurement range becomes the 320
A range.
37. Press the OPERATE key.
The status becomes Standby.
AUTO NULL AZERO
Note
IM-00.0027uA
VS:-20.000V L: 300.00uA *DC
