ADCMT 6244 User Manual

6243/44 DC Voltage Current Source/Monitor Operation Manual
2.4 Saving and Loading Parameters
2-44
(2) Saving and loading parameters
Saving parameters
1. Press the MENU key and select PARAMETER SAVE in the parameter group.
2. Press the key and select a saving area by rotating the Data knob.
3. Press the key.
The following display appears.
4. Press the DIRECT key.
Upon saving completion, “Done” appears.
5. Press the EXIT key.
The measurement screen returns.
Loading parameters
1. Press the MENU key and select PARAMETER LOAD in the parameter group.
2. Press the key and select a loading area by rotating the Data knob.
3. Press the key.
The following display appears.
4. Press the DIRECT key.
Upon loading completion, “Done” appears.
5. Press the EXIT key.
The measurement screen returns.
AZERO
Save 0
Execute (Press DIRECT Key)
AZERO
Load 0
Execute (Press DIRECT Key)

ADCMT 6244 Specifications

General

Brand	ADCMT
Model	6244
Category	Measuring Instruments
Language	English
