7352 Series Digital Multimeter Operation Manual
8.9 System Recovery Procedure
8-20
Each trigger delay
for the right and left
displays
OFF OFF Saved value Selecting USER0-3 0
Sampling count 1 1 Saved value Selecting USER0-3 1
Memory store OFF OFF Saved value Selecting USER0-3 OFF
Continuity
threshold constant
10  10  Saved value Selecting USER0-3 10 
Trigger count 1 1 Saved value Selecting USER0-3 1
Trigger source IMMediate IMMediate Saved value Selecting USER0-3 IMMediate
PASS/FAIL buzzer OFF OFF Saved value Selecting USER0-3 OFF
Buzzer OFF OFF Saved value Selecting USER0-3 OFF
Interface USB USB Saved value
GPIB address 1 1 Saved value
USB ID 1 1 Saved value
Baud rate 9600 9600 Saved value
Data length 8 8 Saved value
Parity None None Saved value
Stop bits 1 1 Saved value
Echo OFF OFF Saved value
Talk only OFF OFF Saved value
Header output ON ON Saved value
Output data element OFF OFF Saved value Selecting USER0-3 OFF
Output data
selection
Right and
left sides
Right and
left sides
Saved value Selecting USER0-3 Right and
left sides
Panel lock OFF Saved value
Disabling function ENA ENA Saved value
PSC flag 1 1 Saved value
Programming
language
ADC ADC Saved value
Continue setting OFF OFF Saved value *1
Password 0000 Saved value
Measurement
memory
Empty Empty Empty Empty Empty Empty
Blank: No Action
Saved value: Last setting value when the power is turned off.
*1: By selecting the initial value for continue setting
Table 8-5 Initial Values of Setting Parameters (2 of 3)
Parameter
Left side
display
Right side
display
When
shipping
Selecting
DFLT
from INIT
in MENU
Selecting
P.OFF from
‘P.ON.LD’
‘LOAD’ in PARAM *RST *CLS DCL
