Replacing the Bearings in the Mandrel
All Bearings in the Mandrel should be replaced with new once annually.
Items Needed to Replace the Mandrel’s Bearings:
• Cut-Resistant Work Gloves
• Screwdriver
• New Support Bearings – 4 sets
• New Film Drive Bearings – 4 sets
• New Applicator Bearings – 2 sets
To Replace the Mandrel’s Bearings:
Remove the Mandrel (see “Removing the Mandrel” on page 152).
Use the Screwdriver to push out the Axles for all Bearings in the Mandrel, making note
of which Axle goes with which location on the Mandrel. The Axles are only held in place
by tension/friction.
Replacing All Bearings and Axles
Axles
Bearings
Mandrel
