Maintenance
For maintenance beyond what is described in this User Guide, please contact your authorized
AFM distributor.
ATTENTION: The LX-150 is a complex piece of machinery. Do not attempt to
perform maintenance or repairs other than those described in this User Guide.
Failure to follow this directive can result in injury, can damage the equipment, and
will void the warranty. If in doubt, contact your AFM distributor.
WARNING: Always wear proper safety equipment, including Cut-Resistant Work
Gloves, when operating or maintaining the LX-150.
Preventative Maintenance Schedule
Following the preventative maintenance schedule below can help ensure optimal performance,
minimize downtime, and help with budgeting for required replacement parts that should be
ordered in advance.
ATTENTION: Some maintenance activities below should be performed by an in-
house mechanical professional or trained AFM Service Technician. If in doubt,
please contact your authorized AFM Distributor.
Frequency Procedure
Page That
Describes
Procedure
As Needed
Perform a general cleaning of the system. 149
Clean the Cutter Notch. 154
Weekly
Clean the Eye of the Print Reading Sensor. 150
Clean the Eye and Reflector of the Work Detective Sensor. 151
Every 3
Weeks
Replace all Cutter Blades. 162
Check the Cutter Drive Belt. 165
Check the Timing Belt. 166
Check the Film Feed Drive Belt. 159
Check the Bearings in the Mandrel and the Wheels that touch them. 155
