Greasing the Shafts of the Film Drive Wheel Adjusts
Once a year, the Shafts of the Film Drive Wheel Adjusts should be lightly greased to ensure
smooth performance.
AFM-4510001-00304-01
Shafts of the Film Drive Wheel Adjusts
(5) Shafts of the Film
Drive Wheel Adjusts
AFM-4510001-00111-01
(5) Shafts of the Film
Drive Wheel Adjusts
