Installing the Mandrel
Before the position of the LX-150 can be fine-tuned, the Mandrel must be installed. The
Mandrel slides down through the hole in the Cutter Assembly. It is held in place mainly by
tension with the Support Wheels, Film Drive Wheels, and Applicator Wheels.
WARNING: When installing the Mandrel, use extreme caution near the Cutter
Assembly. Cutter Blades are very sharp and can easily cause severe cuts.
ATTENTION: Failure to hold the Mandrel firmly by hand when installing it will
result in the Mandrel falling, potentially damaging it and the LX-150, and
voiding the warranty.
VIDEO: Installing the Mandrel
To see a video of this procedure, click this link:
https://youtu.be/_I6lIKRz6qQ
Or scan the QR code at right using the camera app on your mobile
device.
Needed to Install the Mandrel:
• Cut-Resistant Work Gloves
To Install the Mandrel:
Be sure that the LX-150 and UR-1 are turned off and unplugged from any power
source.
Open the Front Door of the LX-150.
Be sure that the Cutter Assembly has been properly installed.
Unlock the Applicator Wheels and move them outward, away from the Mandrel path
(page
115).
