Standard Accessories
A Timing Screw Assembly and Brushdown Assembly are standard accessories included with
the LX-150 Shrink Sleeve Label and Tamper-Evident Band Applicator.
Timing Screw Assembly
Part Number 4502310R and 4502310L (400mm) or
4501973R and 4501973L (800mm)
The Timing Screw Assembly is mounted to the Conveyor upstream from the LX-150, and
guides bottles into the machine at a consistent, evenly spaced rate. A 15.75" (400mm) or
31.50" (800mm) Timing Screw Assembly is included as a standard part of LX-150 Shrink
Sleeve Label Applicator. Each customer’s Timing Screw is made to fit their specific bottle,
with a small range of tolerance. Bottle diameter dictates the pocket size and pitch of a
Timing Screw. AFM can custom build additional Timing Screws to suit a wide variety of
labeling situations.
400 mm Timing Screw Assembly
800 mm Timing Screw Assembly
AFM-4510001-00031-01
AFM-4510001-00032-01
