AFM LX-150 - Greasing the Shafts of the Support Wheel Adjusts

Maintenance 175
4510001 REV B - 220620
Greasing the Shafts of the Support Wheel Adjusts
Once a year, the Shafts of the Film Drive Wheel Adjusts and Support Wheel Adjusts should be
lightly greased to ensure smooth performance.
Shafts of the Support Wheel Adjusts
(3) Shafts of the Upper
Support Wheel Adjusts
AFM-4510001-00110-01
AFM-4510001-00111-01
(3) Shafts of the Lower
Support Wheel Adjusts
