Introduction 41
4510001 REV B - 220620
System Specifications
Power Requirements
220VAC, 50/60 Hz, 3-Phase or
480VAC, 50/60 Hz, 3-Phase
NOTE: Depending on model, can accept power from 208-240V or a
480V power supply
Motors 60W x 2, 90W x 750W x 2
Speed Up to 300 BPM (bottles per minute)* (PET film, cut length 100 mm)
Film “Lay Flat” Width 1.89″ – 9.45″ 48 – 240 mm
Cut Length 1.58″ – 9.84″ 40 – 250 mm
Film Thickness 0.0014″ – 0.027″ 0.035 – 0.07mm
Film Material OPS, PVC, PET
* Speed will vary with the shape and types of items, thickness, and length of shrinkable film. Maximum
speed will be determined by actual running conditions.
NOTE: Formula for calculating correct film “lay flat” width (cylindrical bottles):
(Bottle Diameter + 2~4 mm) x 1.57
NOTE: Bottles in irregular shapes (square, rectangular, oval, etc.) require special tooling,
including irregular Mandrels, Timing Screws and Cutter Assemblies. All of these can be
custom built by AFM for the LX-150.
