Software 79
4510001 REV B - 220620
Common Buttons
A few buttons are seen on numerous Screens. Their functions are described below.
Main Screen Tabs:
Accesses one of the four main screens. Whichever Main Screen Tab is blue is the one
that is currently in use.
“Buzzer Stop” Button:
When an alarm is triggered, this button turns the Buzzer off.
“Fault Reset” Button:
When an alarm is triggered, this button resets the alarm to be able to be triggered again.
This button does not resolve the problem that led to the alarm being triggered.
“Previous” Button:
Advances to the previous screen on the same level in the Software Map.
“Next” Button:
Advances to the next screen on the same level in the Software Map.
“Exit” Button:
Returns to the previous level up in the Software Map.
