48 Installation
4510001 REV B – 220620
Physical Installation
VIDEO: Equipment Setup
To see a video of this procedure, click this link:
https://youtu.be/shn5o7MZXbM
Or scan the QR code at right using the camera app on your mobile
device.
Needed for Entire Installation Process:
• Forklift • Large Crescent Wrench
•
Total of at least 3 people to move the machines
•
Cut-Resistant Work Gloves
• Licensed electrician • Level
• Proper Plug Connection (not included) for the end of
the Power Cable: 3-phase, 220V 50/60 Hz, grounded
• Allen Wrench (included in
Tool Kit)
• Code-compliant, 3-phase, 220V 50/60 Hz grounded
AC power supply
• Sturdy Ladder (if installing
Turn Bar)
Installing the LX-150
Items Needed to Install the LX-150:
• Forklift
• At least 3 people to move the machine
• Large Crescent Wrench
To Install the LX-150:
Find a suitable location for the system:
a. Near a code-compliant, 3-phase, 220V 50/60 Hz grounded power supply.
b. Adequate access to the UR-1 and LX-150 from all sides.
Have a licensed Forklift operator remove the LX-150 from its shipping container.
If needed, use the Crescent Wrench to raise the feet of the LX-150 above the level of
the Casters, so that the LX-150 can easily roll on the Casters.
To Next Page
