Installation 53
4510001 REV B - 220620
Installing the Cutter Assembly
Before the position of the LX-150 can be fine-tuned, the Cutter Assembly must be installed.
The Cutter Assembly slides horizontally like a drawer into the Cutter Support Arms inside
the LX-150 Chassis.
WARNING: When handling the Cutter Assembly, use extreme caution. Cutter
Blades are very sharp and can easily cause severe cuts.
WARNING: The Cutter Guard is an important safety feature. Never operate the
LX-150 without the Cutter Guard properly installed.
VIDEO: Cutter Adjustments
To see a video of this procedure, click this link:
https://www.youtube.com/watch?v=036vSOgbL0A
Or scan the QR code at right using the camera app on your mobile
device.
Time: 2:20 – 2:52
Needed to Install the Cutter Assembly:
• Allen Wrench (included in Tool Kit)
• Cut-Resistant Work Gloves
To Install the Cutter Assembly:
Be sure that the LX-150 is turned off and unplugged from any power source.
Open the Front Door of the LX-150.
Slide the Cutter Guard like a drawer in between the lower part of the Cutter Support
Arms.
Insert the 2 Screws through the End Cap of the Cutter Assembly and into the ends of
both Cutter Support Arms of the LX-150 and use the Allen Wrench to tighten them to
secure the Cutter Assembly in position.
