52 Installation
4510001 REV B – 220620
Use the Laser Level to adjust the position of the UR-1 so that this point on the UR-1
aligns with the centerline of the Conveyor Belt.
Place the Level on the Splicing Table and use the Crescent Wrench to adjust the
Feet of the UR-1 so that the Splicing Table is level.
Making sure that the UR-1 is perfectly parallel to the Conveyor, use the Conveyor
Mounts to secure the UR-1 to the Conveyor in its current position.
