AFM LX-150 - Page 222

222 Diagrams and Parts Lists
4510001 REV B – 220620
Item Part Number Description Specification Quantity
1
4500173
BEARING
5BE016801ZZJ
2
2
4500178
CUTTER BEARINGS
5BE016902ZZJ
22
3.1 4501171 TIMING BELT (D25~80)
W=3/8” XL L=384
5BB023X384XL
1
3.2 4501707 TIMING BELT (D50~120)
W=3/8” XL L=444
5BB023X444XL
1
3.3 4501697 TIMING BELT (D70~150)
W=3/8” XL L=480
5BB023X480XL
1
4
4501161
CUTTER BLADES
5EA650.5X18X110
Varies
Item Part Number Description Specification Quantity
E1
4501728
TIMING PULLEYS
LG150T-EC01
5
E2
4503003
TIMING PULLEYS
LG150T-EC02X2
2
E3
4501741
PULLEYS
LG150T-EC03
1
E4
4503713
PLATES
LG150T-EM01
1
E5
4503319
SET COLLARS
LG150T-EM02
5
E6
4500224
HOUSING
LG150T-EM03
5
E7
4503271
SET COLLARS
LG150T-EM04
5
E8
4503263
AXLS
LG150T-EM05
5
E9
4503261
PULLEYS
LG150T-EM06
6
E10
4503262
SET COLLARS
LG150T-EM07
6
E11
4503264
PLATES
LG150T-EM08
1
E12
4503328
CLAMPS
LG150T-EM09
1
E13
4503327
AXLS
LG150T-EM10
1
E14
4503265
AXLS
LG150T-EM11
1
E15
4503714
PANELS
LG150T-EP01
1
E16
4503715
PLATES
LG150T-EP02
1
E17
4503340
PLATES
LG150T-EP03
1
