Software 97
4510001 REV B - 220620
buttons may also do nothing, because the corresponding peripheral is not used by the
purchaser.
“Screw” Button:
Activates the Timing Screw so that it can be used during the current run. Once bottles are
backed up behind the Timing Screw Sensor, the Timing Screw will start turning about two
seconds after the Start Button on the HMI is pressed.
“H-Perf” Button:
Activates a Horizontal Perforator, if relevant, so that it can be used during the current run.
The Horizontal Perforator will start when the Start Button on the HMI is pressed.
“Printer” Button:
Activates an optional Printer, if relevant, so that it can be used during the current run. The
Printer will start when the Start Button on the HMI is pressed.
“Brush” Button:
Activates the Brushdown Assemblies so that they can be used during the current run. The
Brushdown Assemblies will start when the Start Button on the HMI is pressed.
“Aux Belt” Button:
Activates the Auxiliary Belts / Bottle Holding Devices, if relevant, so that they can be used
during the current run. The Auxiliary Belts / Bottle Holding Devices will start when the Start
Button on the HMI is pressed.
