Status Indicators
Status Indicators
Two status indicators are located on the front of the module. The lower left
indicates the power supply status, the upper right indicates the module status.
Figure 32 Location of Status Indicators
Power Supply Indicator
The power supply indicator is integrated into the main power switch. When
the indicator is illuminated (green) the power is ON.
