188 Agilent 1200 Infinity Series DAD User Manual
10 Parts and Materials for Maintenance
Overview of Maintenance Parts
Overview of Maintenance Parts
For cables refer to “Cable Overview” on page 192.
For bio-inert modules use bio-inert parts only!
Item p/n Description
1 5190-0917 Long-life Deuterium lamp (8-pin) with RFID tag
2 G4212-60008
Max-Light Cartridge Cell (10 mm, V(
σ) 1.0 µL)
2 G5615-60018
Max-Light Cartridge Cell Bio-inert (10 mm, V(
σ) 1.0 µL)
includes Peek Capillary 1.5 m i.d. 0.18 mm (0890-1763) and PEEK
Fittings 10/PK (5063-6591)
3 G4212-60007
Max-Light Cartridge Cell (60 mm, V(σ) 4.0 µL)
3 G5615-60017
Max-Light Cartridge Cell Bio-inert (60 mm, V(
σ) 4.0 µL)
includes Peek Capillary 1.5 m i.d. 0.18 mm (0890-1763) and PEEK
Fittings 10/PK (5063-6591)
3 G4212-60032
HDR Max-Light Cartridge Cell (3.7 mm, V(σ) 0.4 µL)
3 G4212-60038
ULD Max-Light Cartridge Cell (10 mm, V(σ) 0.6 µL)
4 G4212-60011 Max-Light Cartridge Test Cell
5 5067-4660 Inlet Capillary SST 0.12 mm I.D., 220 mm long
6 5062-2462 PTFE Tubing flexible i.d. 0.8 mm, o.d. 1.6 mm, 2 m, re-order 5 m
(flow cell to waste)
7 5067-4691 Front Panel DAD/VWD/FLD (1260/1290)
8 5041-8388 Leak funnel
9 5041-8389 Leak funnel holder
10 5063-6527 Tubing assembly, i.d. 6 mm, o.d. 9 mm, 1.2 m (to waste)
11 G4212-40027 Leak downpipe
12 G4208A Instant Pilot
Instant Pilot G4208A (requires firmware B.02.11 or above).
