Agilent Technologies 1200 Infinity Series User Manual

Agilent 1200 Infinity Series DAD User Manual 37
Installing the Module
3
Optimizing the Stack Configuration
Two Stack Configuration
Two Stack Configuration for Agilent 1260 Infinity LC
To avoid excessive height of the stack when the autosampler thermostat is
added to the system it is recommended to form two stacks. Some users prefer
the lower height of this arrangement even without the autosampler
thermostat. A slightly longer capillary is required between the pump and
autosampler. (See Figure 11 on page 37 and Figure 12 on page 38).
Figure 11 Recommended Two Stack Configuration for 1260 Infinity (Front View)
>chiVciE^adi
9ZiZXidg
8dajbcXdbeVgibZci
HdakZciXVW^cZi
9Z\VhhZgdei^dcVa
Ejbe
I]ZgbdhiVi[dgi]Z6AH$;gVXi^dcXdaaZXidgdei^dcVa
6jidhVbeaZg6AH$;gVXi^dcXdaaZXidg
