Agilent 1200 Infinity Series DAD User Manual 35
Installing the Module
3
Optimizing the Stack Configuration
One Stack Configuration for Agilent 1290 Infinity LC
Ensure optimum performance by installing the modules of the Agilent 1290
Infinity Binary LC System in the following configuration (See Figure 9 on
page 35 and Figure 10 on page 36). This configuration optimizes the flow path
for minimum delay volume and minimizes the bench space required.
The Agilent 1290 Infinity Binary Pump should always be installed at the
bottom of the stack.
Figure 9 Recommended stack configuration for 1290 Infinity with binary pump (front view)
9ZiZXidg
6jidhVbeaZg
Ejbe
HdakZciXVW^cZi
8dajbcXdbeVgibZci
>chiVciE^adi
