Agilent Technologies E4406A VSA Series Service Guide

Chapter 2 105
Block Diagrams
Mnemonics and Connectors
Table 2-11 A21J10 Digital IF Connector
Pin Signal Pin Signal
1 ACOM 51 ACOM
2 ACOM 52 ACOM
3 ACOM 53 ACOM
4 ACOM 54 SR_L
5 ACOM 55 SR_H
6 ACOM 56 ACOM
7 ACOM 57 NC
8 ACOM 58 ACOM
9 ACOM 59 ACOM
10 ACOM 60 ACOM
11 ACOM 61 ACOM
12 ACOM 62 RANGE
13 ACOM 63 ACOM
14 ACOM 64 ACOM
15 ACOM 65 NC
16 ACOM 66 LO_LOCK
17 ACOM 67 NC
18 ACOM 68 OPT_TRIG2
19 ACOM 69 OPT_TRIG1
20 ACOM 70 TRIG2
21 ACOM 71 TRIG1
22 ACOM 72 HPUP
23 SWEEP_ARM 73 LSRQ
24 ACOM 74 MISO
25 SWEEP_TRIG 75 LCNTRL
26 ACOM 76 MOSI
27 GATE_ARM 77 LDATA
28 ACOM 78 SCLK
29 GATE_TRIG 79 LADDR
30 ACOM 80 ACOM
31 ACOM 81 ACOM
32 P5.2 82 P5.2
33 P5.2 83 P5.2
34 ACOM 84 ACOM
35N1585N15
36N1586N15
37 ACOM 87 ACOM
38 ACOM 88 ACOM
39 N5.2 89 N5.2
40 N5.2 90 N5.2
41 ACOM 91 ACOM
42 P9 92 P9
43 P9 93 P9
44 ACOM 94 ACOM
45 ACOM 95 ACOM
46P1596P15
47P1597P15
48 ACOM 98 ACOM
49P3299P32
50 ACOM 100 ACOM
