Agilent Technologies E4406A VSA Series - Page 106

106 Chapter 2
Block Diagrams
Mnemonics and Connectors
Table 2-12 A21J11 Front Panel Ribbon Cable Connector
Pin Signal Pin Signal
1 DCOM 51 FP_INTRL
2 DCOM 52 FP_A0
3VDL53FP_A1
4 DCOM 54 FP_A2
5 DCOM 55 FP_A3
6 DCOM 56 FP_D0
7 VDL 57 FP_D1
8 DCOM 58 FP_D2
9 DCOM 59 FP_D3
10 DCOM 60 FP_D4
11 VDL 61 FP_D5
12 DCOM 62 FP_D6
13 DCOM 63 FP_D7
14 DCOM 64 FP_W_RL
15 VDL 65 FP_CLK
16 DCOM 66 FP_PWR_RST_L
17 DCOM 67 FP_CSL
18 DCOM 68 FP_DOTCLK
19 VCC 69 FP_CBLANKL
20 DCOM 70 FP_HSYNCL
21 DCOM 71 FP_VSYNCL
22 DCOM 72 FP_RED0
23 VCC 73 FP_RED1
24 DCOM 74 FP_RED2
25 DCOM 75 FP_RED3
26 DCOM 76 FP_GREEN0
27 VCC 77 FP_GREEN1
28 DCOM 78 FP_GREEN2
29 DCOM 79 FP_GREEN3
30 DCOM 80 FP_BLUE0
31 VCC 81 FP_BLUE1
32 DCOM 82 FP_BLUE2
33 DCOM 83 FP_BLUE3
34 DCOM 84 ACOM
35 ACOM 85 PROBE_P15
36 ACOM 86 PROBE_P15
37 ACOM 87 PROBE_P15
38 ACOM 88 PROBE_N12.6
39 ACOM 89 PROBE_N12.6
40 ACOM 90 PROBE_N12.6
41 ACOM 91 FP_P5.2
42 ACOM 92 FP_P5.2
43 ACOM 93 FP_P5.2
44 ACOM 94 FP_P15SBY
45 ACOM 95 NC
46 ACOM 96 ACOM
47 ACOM 97 LINE_OUT_R
48 ACOM 98 LINE_OUT_COM
49 ACOM 99 LINE_OUT_L
50 ACOM 100 ACOM
