Agilent Technologies E4406A VSA Series Service Guide

Chapter 2 107
Block Diagrams
Mnemonics and Connectors
Table 2-13 A21J12 CPU - PCMCIA/Floppy Connector
Pin Signal Pin Signal
1 ACOM 41 NC
2NC42NC
3NC43NC
4NC44NC
5NC45ACOM
6 DCOM 46 FLOPPY_MID
7 FP_P12 47 FLOPPY_WEL
8 DCOM 48 FLOPPY_WDL
9 FP_P12 49 FLOPPY_STEPL
10 DCOM 50 FLOPPY_DIRCL
11 FP_P12 51 FLOPPY_HSL
12 DCOM 52 FLOPPY_DS1L
13 VDL 53 FLOPPY_DS3L
14 DCOM 54 FLOPPY_RDDL
15 VDL 55 FLOPPY_WPL
16 DCOM 56 FLOPPY_TR00L
17 VDL 57 FLOPPY_IDXL
18 DCOM 58 FLOPPY_DCHGL
19 VDL 59 FLOPPY_READY
20 DCOM 60 PCMCIA_WEL
21 VCC 61 PCMCIA_OEL
22 DCOM 62 PCMCIA_CLK7
23 VCC 63 PCMCIA_CS1L
24 DCOM 64 PCMCIA_CS2L
25 VCC 65 PCMCIA_RSTL
26 DCOM 66 PCMCIA_INTRL
27 VCC 67 PCMCIA_LTCHENL
28 DCOM 68 PCMCIA_AD0
29 VCC 69 PCMCIA_AD1
30 DCOM 70 PCMCIA_AD2
31 VCC 71 PCMCIA_D0
32 DCOM 72 PCMCIA_D1
33 VCC 73 PCMCIA_D2
34 DCOM 74 PCMCIA_D3
35 VCC 75 PCMCIA_D4
36 DCOM 76 PCMCIA_D5
37 VCC 77 PCMCIA_D6
38 DCOM 78 PCMCIA_D7
39 NC 79 NC
40 NC 80 NC
