Chapter 3 137
Parts List
Replaceable Parts
CPU shim 2 (refer to Figure 3-20 on page 162) E4406-00077
Dress Panel, SCSI E4406-00017
Trim, Side 5041-9172
Rear Feet 5041-9611
Bottom Feet 5041-9167
Strap Handles E4400-60026
Motherboard Shield Assembly E4406-60024
Ferrite, W6 Flat Panel Interface Cable 9170-1727
Ferrite, W10 Disk Drive Cable 9170-1726
Shield, Ferrite E4406-20105
CPU Bottom Plastic Spacers 0380-4163
Memory Plastic Standoffs 0380-4663
Mid Web Fan Plastic Rivet 0361-1272
Nut, W20 2950-0035
Nut, A27 2950-0154
Screw M3x0.5 8mm-LG
(Crest Washer-Pan Head-TORX)
0515-0372
Screw M3x0.5 6mm-LG
(Flat Head - TORX)
0515-1227
Screws, Jack 0380-1858
Screwlock Stand Off-Hex
0.312-IN-LG, SCSI
1252-5828
Screw M4x0.7 25mm-LG, Rear Feet 0515-1619
Washer-LK HLC No. 10
0.194-IN-ID, GPIB
2190-0034
Standoff-HEX
0.327-IN-LG, GPIB
0380-0644
a. For instruments with serial numbers between US3845101 and
US40061423, you must replace the Front Frame Assembly, Chassis, and
Rear Frame Assembly together.
Table 3-5 Mechanical Parts
Description Agilent Part Number
