Agilent Technologies E4406A VSA Series Service Guide

138 Chapter 3
Parts List
Replaceable Parts
Table 3-6 Cables
Reference
Designator
Description Agilent Part Number
W3 Cable, Coax
Ext Trig In, Front Panel
E4406-60139
W6 Cable, Flat Flex
Flat Panel Interface
8120-8480
(Prefix US/MY4402 and below)
W6 Cable, Flat Flex
Flat Panel Interface
8121-1419
(Prefix US/MY46xx and above)
W8 Cable, Ribbon
Front Panel
8120-8463
W9 Cable, Semi-Rigid, SMA
RF Input
E4406-20041
a
W10 Cable, Flat Flex
Disk Drive
8120-8461
W11 Cable, Semi-Rigid, Type-M
4 GHz LO
E4406-20040
a
W12 Cable, Coax
21.4 MHz - RF to Analog IF
E4406-60027
a
W13 Cable, Coax
7.5 MHz - Digital IF to Analog IF
8120-5022
W19 Cable, Coax, Type-M BNC
321.4 MHz OUT, Rear Panel (Option 300)
E4406-60071
a
W20 Cable, Coax
EXT Trig In, Rear Panel
8120-5055
W21, W22 Inverter, A3 8120-8462
W23 Backlight, Top (235 mm) 8120-8460
W24 Backlight, Bottom (264 mm) 8120-8459
W25 Cable, Flat Flex
Rear Panel, I/O
8120-8493
W26 Fan
Part of B1, B2, B3
W27 Cable, Backlight Extension (63 mm) 8121-1420
(Prefix US/MY46xx and above)
W32 Cable, Coax
I (12) Input (Option B7C)
E4406-60161
