Agilent Technologies FieldFox N9913A User Manual

Power Meter Mode 139
How to set Single or Continuous
 Press Sweep 3.
 Then choose one of the following:
o Single Automatically sets Continuous OFF and causes FieldFox to make
ONE measurement, then hold for the next Single key press. When a data
trace is displayed, the entire trace is measured, then holds. The Hold
annotation changes to an arrow --> while the measurement occurs.
o Continuous Makes continuous measurements. This is the typical setting
when battery power is not critical.
You can also use Run / Hold +/- to toggle between Single and Continuous.
Step Detection Mode
The FieldFox supports the Step Detection feature that is present in Agilent USB
power sensors. When enabled, this feature reduces settling time after a
significant step in the measured power. For more information, please refer to the
USB Power Meter documentation.
How to set Step Detection mode
 Press Meas Setup 4.
 Then Step Detection ON Off
 Then choose from the following:
o ON Enables step detection (default setting)
o OFF Disables step detection
Limits
In Power Meter Mode, Minimum and Maximum limits set a visible range of
acceptable readings between these two values. Readings that are below the
minimum or above the maximum are clearly visible on the power meter display.
How to set Limits
 Press Limit 8.
 Then choose from the following:
o Min Limit On Off Toggles the display of the Minimum limit ON and OFF.
o Min Limit Value Sets the Minimum limit power value. Power reading lower
than this will exceed the limit.
o Max Limit On Off Toggles the display of the Maximum limit ON and OFF.
o Max Limit Value Sets the Maximum limit power value. Power reading
higher than this will exceed the limit.
