User Guide
ROTARY SPEAKER
ROTARY SPEAKER
This mono-in / stereo-out effect simulates rotary speakers for organ sound.
• Rate1 (0.1Hz - 10.0Hz) Adjusts the rotation speed (Rate1) of the speakers.
• Rate2 (0.1Hz - 10.0Hz) Adjusts the rotation speed (Rate2) of the speakers.
• Accel (0.1sec - 10sec) Adjusts the time (duration) taken for switching from
Rate1 to Rate 2.
• Init (R1/R2) Sets the initial rotation speed (Rate1/Rate2).
Pressing the additional [F5] TRIGGER softkey
repeatedly toggles the rotation speed between
Rate 1 and Rate 2.
Use the Accel parameter to adjust the time (du-
ration) taken for switching between two
speeds.
PAN
AUTO PAN
This auto pan effect automatically rotates the stereo image of the sound between left and right.
• Rate (0.1Hz - 10.0Hz)
Adjusts the speed of panning.
• Mode Pan:
A common auto pan.
L>R:
Simulates a sound source that rotates counterclockwise.
R>L:
Simulates a sound source that rotates clockwise .
• Width (0% - 100% ) Adjusts the panning width.
TRIGGERED PAN
This auto pan effect becomes enabled when the output
level of one of AUX sends 1 - 4 exceeds a certain level.
You can also press the [F5] (TRIGGER) softkey to start
the auto pan effect manually.
• Rate
(0.1Hz
-
10.0Hz)
Adjusts the speed of panning.
• Mode
(Pan / L>R / R>L)
Sets the effect of pan-
ning. (Refer to AUTO PAN.)
• Trigger
AUX-1
-
AUX-4
Selects which AUX signal enables the auto pan effect.
MANUAL
Pressing the [F5] key triggers the auto pan effect.
• Thresh
(-60dB
-
0dB)
Sets the signal level at which the auto pan becomes effective.
• Width
(0%
-
100%)
Adjusts the panning width.
ROTARY SPEAKER
