145
User Guide
EXPANDER GATE
This monaural effect limits signals at a certain level (threshold) or lower and expands the
dynamic range, providing an effect opposite to the compressor effect.
• Link (ON/OFF) Links FX1 and FX2 (or FX 3 and FX4). See previous page.
• Thresh (-60dB - 0dB) Adjusts the threshold level at which the effect is enabled
• Ratio (2:1 - 100:1) Adjusts the compression ratio for signals that are lower than the
threshold level
• Output
(-24dB
-
+24dB)
Adjusts the output level of the effect sound
• Attack (0ms - 127ms) Adjusts the attack time of the effect
• Release (0ms - 127ms) Adjusts the release time of the effect
Pressing the [F5] (MORE) softkey provides access to another parameter:
• Hold (0 - 127) Adjusts the hold time of the effect
NOISE GATE
This monaural effect mutes signals below a certain level (threshold).
This is useful for cutting noise during silent parts of a performance.
• Link (ON/OFF) Links FX1 and FX2 (or FX 3 and FX4). See previous page.
• Thresh (-60dB - 0dB) Adjusts the level at which the gate opens or closes.
•Key
(AUX-1
-
AUX-4)
Selects the source signal that triggers the gate to open or close
(AUX send 1_4)
• Output
(-24dB
-
+24dB)
Adjusts the output level of the effect sound
• Attack (0ms - 127ms) Adjusts the attack time of the effect
• Release (0ms - 127ms) Adjusts the release time of the effect
Pressing the [F5] (MORE) softkey provides access to another parameter:
• Hold (0 - 127) Adjusts the hold time of the effect.
DYNAMICS
