The following table list the main features and differences of the two option cards X4IP
and X5IP:
Feature List X4IP X5IP
WAN Port fix vc channel mapping(4) flexiable vc channel
mapping(8)
LCAS Dsiabled Enabled
SDH TP VC12 VC3 TP function VC12 VC3 TP function
ether Encapsulation EOS/GFP GFP
LAN Port 10/100M FE port(4 E) 10/100/1000M GE port
SFP No Yes
L2 switch VPN/IEEE(1q and 1ad) IEEE(1q and 1ad)
STP/GVRP/ IRUP/SVDP Yes Yes
QOS Yes Yes
Mac prov Yes Yes
RTD Yes Yes
LPT No Yes (for all ports)
PM per port Yes Yes
PM per flow Yes Yes
PM per TC Yes Yes
increase vlan support 64 static/64 dynamic 64 static/64 dynamic
LED test No Yes
Ethernet Interfaces
On the faceplate, the X5IP option card provides the following interfaces.
• 10/100/1000BASE-T(X) electrical Ethernet interface using RJ-45 connector
supports 10BASE-T, 100BASE-T(X), or 1000BASE-T specifications.
• 10/100BASE-T(X) electrical Ethernet interface using RJ-45 connector supports
10BASE-T and 100BASE-TX specifications.
• 1000BASE-SX optical Ethernet interface, covers a distance of 550 m over 50 µm
MMF with an operating wavelength of 770-860 nm.
• 1000BASE-LX optical Ethernet interface, covers a distance of 5 km over 10 µm
SMF with an operating wavelength of 1310 nm.
• 1000BASE-ZX optical Gigabit Ethernet interface in single fiber mode, covers a
distance of 70 km with an operating wavelength of 1550 nm for long haul
transmission.
Traffic provisioning
Ethernet over SDH
....................................................................................................................................................................................................................................
