Example
After the bridge has received a packet from station C it knows that station C is
attached to port 2. When the bridge knows to which ports a station is attached, it will
send packets with destination addresses of these stations only to the port the station is
attached to (for example, a packet from station B to station C is only forwarded to port
2). When a destination address of a packet is of a station in its own segment, the
packet is not forwarded by the bridge (for example, a packet from station D to station
E).
Quality of service
Refer to “Quality of Service (QoS) overview” (p. 8-81).
Traffic provisioning
Ethernet over SDH
....................................................................................................................................................................................................................................
365-312-807R7.2
Issue 4, May 2007
Alcatel-Lucent - Proprietary
See notice on first page
8-39
