Result: The Termination Point List window appears with a list of termination
points.
...................................................................................................................................................................................................
4
Select the termination point from the list and click Details.
Result: The Provisioned Termination Point Information window appears with
information about the selected termination point. The information about the path
trace is displayed in the J0/J1/J2 Trail Trace Identifier area.
...................................................................................................................................................................................................
5
Click Edit.
Result: The Edit Provisioned Termination Point Information window appears.
...................................................................................................................................................................................................
6
CAUTION
If the Trace Identifier Mismatch (TIM) detection is enabled, traffic will be lost when a
mistake in the trace string is made. Upon mismatch, an Alarm Indication Signal (AIS)
is inserted in the downstream signal and Remote Defect Indicator (RDI) is inserted in
the upstream signal (RDI is not inserted if the directionality is unidirectional)
Fill in the label used to be transmitted as path trace and/or the label that is expected to
be received. If no label is used select Non Specific Byte. Check if the accepted path
trace is the same as the expected path trace and enable or disable the TIM detection if
necessary. Click
OK.
Result: The path trace is provisioned and displayed in the Provisioned Termination
Point Information window. If the expected TTI equals the accepted TTI, the
transmission path is well provisioned.
E ND OF STEPS
...................................................................................................................................................................................................
