Ethernet
Service
Flow
Counter Location Unit Threshold X5IP X4IP X8PL
LAN WAN LAN WAN LAN WAN
incom-
ing
bytes of
all red
marked
frames
for one
service
flow
rQIB /port
/Service
or
/virtual
port
/Service
byte - - - - - - -
Note: gQIB is supported in X5IP but not in X4IP.
Ethernet high quality traffic counters
The Ethernet high quality traffic counters provide link load monitoring per traffic class
and color (dropping precedence) for high-priority Ethernet traffic (traffic class 2 or 3,
mapped into the egress queues 2 or 3 respectively).
The following counters are supported for Ethernet high quality traffic:
High
quality
traffic
ethernet
load
PM
Counter Location Unit Threshold X5IP X4IP X8PL
LAN WAN LAN WAN LAN WAN
incom-
ing
bytes of
green
frames
with
traffic
class 2
g2EINB /NR ingr
/TC
/color
byte - x x x x - -
incom-
ing
bytes of
yellow
frames
with
traffic
class 2
y2EINB /NR ingr
/TC
/color
byte - x x x x - -
