Low
quality
traffic
ethernet
PM
Counter Location Unit Threshold X5IP X4IP X8PL
LAN WAN LAN WANLANWAN
number
of
incoming
yellow
frames
with
traffic
class 0
y0EINF /NR ingr
/TC
/color
packet- - - x x - -
number
of
incoming
green
frames
with
traffic
class 1
g1EINF /NR ingr
/TC
/color
packet- - - x x - -
number
of
incoming
yellow
frames
with
traffic
class 1
y1EINF /NR ingr
/TC
/color
packet- - - x x - -
There is no thresholding for Ethernet low quality traffic.
Ethernet service route round trip delay measurements
The round trip delay is measured between two virtual switches within an Ethernet
network by means of a dedicated configurable test frame that determines the “Ethernet
service route”. To enable either a cyclic or a one-time latency measurement to a remote
NE in the TransLAN network, whereby the remote NE can be identified by inserting
its MAC address in the destination MAC address (DA) field of the test frame.
Furthermore, the traffic class, the color (dropping precedence), the VLAN identifier
and the length of the test frames can be specified, because these parameters may have
influence on the delay. The RTD measurement path follows the currently valid
STP-topology. The accuracy of the RTD measurement is 4 ms.
Performance monitoring
Ethernet performance monitoring
....................................................................................................................................................................................................................................
365-312-807R7.2
Issue 4, May 2007
Alcatel-Lucent - Proprietary
See notice on first page
10-23
