VRRP
Router Configuration Guide 449
Adm Up
Indicates that the administrative state of the VRRP instance is up.
Down
Indicates that the administrative state of the VRRP instance is down.
Opr Up
Indicates that the operational state of the VRRP instance is up.
Down
Indicates that the operational state of the VRRP instance is down.
State When owner, backup defines the IP addresses that are advertised
within VRRP advertisement messages.
When non-owner, backup actually creates an IP interface IP address
used for routing IP packets and communicating with the system when
the access commands are defined (ping-reply, telnet-reply, and ssh-
reply).
Pol Id The value that uniquely identifies a Priority Control Policy.
Base Priority The base-priority value used to derive the in-use priority of the virtual
router instance as modified by any optional VRRP priority control
policy.
InUse Priority The current in-use priority associated with the VRRP virtual router
instance.
Msg Int The administrative advertisement message timer used by the master
virtual router instance to send VRRP advertisement messages and to
derive the master down timer as backup.
Inh Int Yes
When the VRRP instance is a non-owner and is operating as a backup
and the master-int-inherit command is enabled, the master down timer
is indirectly derived from the value in the advertisement interval field
of the VRRP message received from the current master.
No
When the VRRP instance is operating as a backup and the master-int-
inherit command is not enabled, the configured advertisement interval
is matched against the value in the advertisement interval field of the
VRRP message received from the current master. If the two values do
not match then the VRRP advertisement is discarded.
If the VRRP instance is operating as a master, this value has no effect.
Backup Addr The backup virtual router IP address.
Table 39: VRRP Instance Output Field Descriptions (Continued)
Label Description
