Common Configuration Tasks
716 Router Configuration Guide
exit
-----------------------------------------
A:ALA-1>config>cflowd#
Version 9 Collector example:
collector 10.10.10.9:2000 version 9
description "v9collector"
template-set mpls-ip
no shutdown
exit
Version 9 and Version 10 Templates
If the collector is configured to use either version 9 or version 10 (IPFIX) formats, the flow
data is sent to the designated collector using one of the predefined templates. The template
used is based on the type of flow for which the data was collected (IPv4, IPv6, MPLS or
Ethernet (Layer 2)), and the configuration of the template-set parameter. Table 70 indicates
the relationship between these values and the corresponding template used to export the flow
data.
Each flow exported, to a collector configured for either version 9 or version 10 formats, will
be sent using one of the above flow template sets. As described above, which template is used
is based on the flow type and how the collector’s template-set parameter is configured.
The following tables specify the fields present in each template.
Table 70: Template-Set
Traffic type Basic MPLS-IP
IPv4 Basic IPv4 MPLS-IPv4
IPv6 Basic IPv6 MPLS-IPv6
MPLS Basic MPLS MPLS-IP
Ethernet L2-IP L2-IP
Table 71: Basic IPv4 Template
Field Name Field ID
IPv4 Src Addr 8
