Table 72: MPLS-IPv4 Template
Field Name Field ID
IPv4 Src Addr 8
IPv4 Dest Addr 12
IPv4 Nexthop 15
BGP Nexthop 18
Ingress Interface 10
Egress Interface 14
Packet Count 2
Byte Count 1
Start Time 22
End Time 21
Flow Start Milliseconds
1
152
Flow End Milliseconds 153
Src Port 7
Dest Port 11
Forwarding Status 89
TCP control Bits (Flags) 6
IPv4 Protocol 4
IPv4 TOS 5
IP version 60
ICMP Type & Code 32
Direction 61
BGP Source ASN 16
BGP Dest ASN 17
Source IPv4 Prefix Length 9
Dest IPv4 Prefix Length 13
MPLS Top Label Type 46
