Allen-Bradley 20F Installation Instructions

112 Rockwell Automation Publication 750-IN001P-EN-P - April 2017
Chapter 3 Lift and Mount the Drive
Figure 76 - IP20, NEMA/UL Type 1, MCC Style Cabinet, Floor Mount Frame 9 Bottom Access
(Enclosure Code L, P, W)
300
(11.8)
531
(20.9)
669
(26.3)
900
(35.4)
1131
(44.5)
1269
(50.0)
1500
(59.1)
1731
(68.1)
69
(2.7)
ø18.0
(0.71)
742
(29.2)
43
(1.7)
270
(10.6)
1
1
1
1
2
2
127
(5.0)
76
(3.0)
440
(17.3)
200
(7.9)
270
(10.6)
440
(17.3)
76
(3.0)
440
(17.3)
800 mm (31.5 in.) Deep Drive with Wiring Bay
No. Description
1 Power wiring conduit plates.
2 Control wiring conduit plates.
