40 Rockwell Automation Publication 750-IN001P-EN-P - April 2017
Chapter 3 Lift and Mount the Drive
Table 7 - Maximum Component Weights – Floor Mount Frames 8…10
Recommended Mounting
Hardware
Use the recommended hardware to mount the drives.
Component Weight, kg (lb)
AC Input Common DC Input
Converter/DC input with precharge 64 (140) 64 (140)
Inverter 222 (490) 165 (363)
Drive assembly (Open, IP00) 286 (630) 229 (504)
Cabinet options assembly with circuit breaker and reactor 296 (653) –
Frame Size Fastener Size Notes
Wall mount
1
M6 (#10 or #12)
2
3
4
5
6M6 (#12)
7 M8 (5/16 in.)
Floor mount
8
M12 (1/2 in.) Property class 8.8 (min)9
10
IMPORTANT Mounting hardware is included with enclosure type F (flange mount) drives.
To meet the enclosure rating, you must use the hardware that is included
with the flange mount drives.
