Power Wiring Chapter 4
Power Cable Types
Acceptable for 200…600
Volt Installations
For detailed information on various cable types that are acceptable for drive
installations, see Wiring and Grounding Guidelines for Pulse-width
Modulated (PWM) AC Drive, publication DRIVES-IN001
.
Wire Recommendations
Motor Considerations
Due to the operational characteristics of AC variable frequency drives, motors
with inverter grade insulation systems that are designed to meet or exceed
NEMA MG1 Part 31.40.4.2 standards for resistance to spikes of 1600 volts are
recommended.
Follow all guidelines when using non-inverter grade motors to avoid premature
motor failures. See Wiring and Grounding Guidelines for Pulse-width
Modulated (PWM) AC Drives, publication DRIVES-IN001
, for
recommendations.
Terminal Block Specifications
Table 10 - Wall Mount Frames 1…5 Power Terminal Block
ATTENTION: National Codes and standards (NEC, BSI, and so forth) and local
codes outline provisions for safely installing electrical equipment.
Installation must comply with specifications regarding wire types, conductor
sizes, branch circuit protection, and disconnect devices. Failure to do so can
result in personal injury and/or equipment damage.
Type Description Min Insulation Rating
Power
(1)(2)
(1) Separate control and signal wires from power wires by at least 0.3 meters (1 foot).
(2) The use of shielded wire for AC input power is not necessary, but is always recommended.
Standard • Four tinned copper conductors with XLPE insulation.
• Copper braid/aluminum foil combination shield and
tinned copper drain wire.
•PVC jacket.
600V,
75 °C (167 °F)
Frame Wire Size Range
(1) (2)
(1) Maximum/minimum wire sizes that the terminal block can accept. These sizes are not recommendations.
(2) Terminal blocks are designed to accept one wire.
Strip Length
mm (in.)
Recommended
Torque
N•m (lb•in)
Recommended Tools
Max
mm
2
(AWG)
Min
mm
2
(AWG)
1
4.0 (10) 0.2 (24) 8.0 (0.31) 0.57 (5.0) #2 Pozidriv, M3 x 7
2
3 16.0 (6) 0.5 (20) 10.0 (0.39) 1.2 (10.6) #2 flat screwdriver
4 25.0 (3) 2.5 (14) 10.0 (0.39) 2.7 (24.0)
#2 Pozidriv
492-C Phillips
0.25 in. flat screwdriver
5 35.0 (1) 10.0 (8) 12.0 (0.5) 4.0 (35.0)
#2 Pozidriv
492-C Phillips
0.25 in. flat screwdriver
