Chapter 4 Power Wiring
Cabinet Options Bay
Accessories
This section describes the cabinet options bay accessories.
Figure 109 - Accessory Overview
1
2
3
4
5
6
Floor Mount Frame 8
Floor Mount Frame 9
No. Description Floor Mount Drive
Frame Size
1Outlet blower (Frame 9) 9
2 Circuit breaker/molded case switch 8, 9
3 Input or output contactor (optional) 8
4Transformer panel 9
5 Input or output reactor (optional) 8, 9
6Reactor fan tray (included with reactor) 9
