I/O Wiring Chapter 5
BACnet/IP Option Module
For complete information on the BACnet/IP option module, see the
PowerFlex 20-750-BNETIP BACnet/IP Option Module User Manual,
publication 750COM-UM005
.
Table 103 - BACnet/IP Option Module Status Indicator Indication
Table 104 - P4 Address Selection Jumper
Table 105 - Ethernet Connector
20-750-BNETIP
Status Indicator Name Description
1 PORT DPI Connection Status
2 MOD Option Module Status
3 NET A BACnet Status
Jumper Position Description
Default network address.
Configured network address.
Name Description
Ethernet RJ45
Connector
BACnet/IP connection to the
Ethernet network.
1
2
3
1 2 3
P4
1 2 3
P4
