Allen-Bradley 20F - Attach Lifting Hardware; Enclosure Code F

Rockwell Automation Publication 750-IN001P-EN-P - April 2017 41
Lift and Mount the Drive Chapter 3
Attach Lifting Hardware
This section provides guidelines on how to attach the lifting hardware.
Figure 13 - Rigging Geometry
Enclosure Code F
Follow these guidelines for drives with enclosure code F.
Figure 14 - Wall Mount Frame 6 Lifting Points – Two Places
>
1
/
2 A
A
<45°
>
1
/
2 A
A
<45°
