Allen-Bradley 20F Installation Instructions

Rockwell Automation Publication 750-IN001P-EN-P - April 2017 183
Power Wiring Chapter 4
Table 22 - 480 Volt AC and 650 Volt DC Input Protection Devices – Floor Mount Frames 8…10
Applied Rating
(1)
Frame
Cont. Output Amps
Duty Catalog
Number
Output Overload Amps
Continuous AC Input
AC Input Integral Semiconductor Fuse Size (170M)
(2)
DC Bay to Bay Integral Semiconductor Fuse Size (170M)
AC Input Protection Devices Recommended for Branch Circuit Protection (Does not apply to 21G Drives with Options)
Input Quantities
DC Input Integral Semiconductor Fuse Size (170M)
(8)
Dual Element Time Delay Fuse
Non-Time Delay Fuse Circuit
Breaker Max Size
(6)
Motor Circuit Protector
(7)
Continuous DC Input
1 min 3 sec Amps Amps Amps 1/Phase
Min
(4)
2/Phase Min
(4)
Max
(5)
1/Phase Min
(4)
2/Phase Min
(4)
Max
(5)
Amps Amps
480V AC Input 650V DC Input 300 Hp 8
370 Heavy 20G…D430 555 666 349 1100 – 450 – 800 450 – 1100 1100 450 407 1600
350 Hp 8 430 Normal 20G…D430 473 666 406 1100 – 550 – 900 550 – 1200 1200 550 473 1600
414 Heavy 20G…D485 621 745 391 1100 – 500 – 900 500 – 1200 1200 500 455 1600 454 Heavy 20G…D545 681 818 428 1100 – 550 – 1000 550 – 1300 1300 550 499 1600
400 Hp 8
485 Light 20G…D430 534 – 458 1100 – 600 – 1000 600 – 1400 1400 600 533 1600 485 Normal 20G…D485 534 745 458 1100 – 600 – 1000 600 – 1400 1400 600 533 1600 485 Heavy 20G…D617 728 926 458 1100 – 600 – 1000 600 – 1400 1400 600 533 1600
450 Hp 8 545 Light 20G…D485 600 – 514 1100 – 650 – 1200 650 – 1600 1600 650 599 1600
545 Normal 20G…D545 600 818 514 1100 – 650 – 1200 650 – 1600 1600 650 599 1600 545 Heavy 20G…D710 818 1065 514 1100 – 650 325 1200 650 325 1600 1600 650 599 1600
500 Hp 8
590 Light 20G…D545 649 – 557 1100 – 700 – 1300 700 – 1700 1700 700 649 1600 617 Normal 20G…D617 679 926 582 1100 – 750 325 1300 750 325 1800 1800 800 678 1600 617 Heavy 20G…D740 926 1110 582 1100 – 750 375 1300 750 375 2400 1800 800 678 1600
600 Hp 8 710 Light 20G…D617 781 – 670 1100 – 850 425 1500 850 425 2100 2100 900 781 1600
710 Normal 20G…D710 781 1065 670 1100 – 850 425 1500 850 425 2100 2100 900 781 1600
650 Hp 8 765 Light 20G…D710 842 – 722 1100 – 1000 500 1700 1000 500 2200 2200 1000 841 1600
740 Normal 20G…D740 814 1110 698 1100 – 900 450 1600 900 450 2200 2200 900 814 1600
700 Hp 8 800 Light 20G…D740 880 – 755 1100 – 1000 500 1800 1000 500 1800 2400 1000 880 1600 600 Hp 9
710 Heavy 20G…D800 1065 1278 670 1100 1400
(3)
850 425 1500 850 425 2000 2000 850 781 1600
(3)
700 Hp 9 795 Heavy 20G…D960 1193 1440 750 1100 1400
(3)
950 475 1700 950 475 2300 2300 950 874 1600
(3)
800 Normal 20G…D800 880 1278 755 1100 1400
(3)
950 475 1700 950 475 2300 2300 950 880 1600
(3)
750 Hp 9 800 Heavy 20G…D1K0 1200 1568 755 1100 1400
(3)
950 475 1700 950 475 2300 2300 950 880 1600
(3)
800 Hp 9 960 Light 20G…D800 1056 – 906 1100 1400
(3)
1150 575 2000 1150 575 2700 2700 1150 1055 1600
(3)
960 Normal 20G…D960 1056 1440 906 1100 1400
(3)
1150 575 2000 1150 575 2700 2700 1150 1055 1600
(3)
960 Heavy 20G…D1K2 1440 1728 906 1100 1400
(3)
1150 575 2000 1150 575 2700 2700 1150 1055 1600
(3)
