Allen-Bradley 20F Installation Instructions

Rockwell Automation Publication 750-IN001P-EN-P - April 2017 195
Power Wiring Chapter 4
Table 29 - Short Circuit Current Ratings – 600V AC Input
Drive Catalog
Number
Duty
Cycle
Hp Short Circuit Current Rating (kA)
Circuit Breaker
Only (P3)
(1)
Circuit Breaker with Input Contactor
(P3 with P11)
(1)
Molded Case Switch Only
(P5)
(2)
Molded Case Switch with Input
Contactor
(P5 with P11)
(2)
21G…E295 LD 350 50 • 18 w/601…700 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25 • 25 w/600 A Class J fuse
ND 300 50 • 18 w/600 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25 • 25 w/600 A Class J fuse
HD 250 50 • 18 w/600 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25 • 25 w/600 A Class J fuse
21G…E355 LD 400 50 • 18 w/601…800 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25 • 25 w/600 A Class J fuse
ND 350 50 • 18 w/601…700 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25 • 25 w/600 A Class J fuse
HD 300 50 • 18 w/600 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25 • 25 w/600 A Class J fuse
21G…E395 LD 450 50 • 30 w/601…900 A Class L fuse
• 30 w/1000 A CB
• 100 w/800 A max Class L fuse • 30 w/800 A Class L fuse
ND 400 50 • 18 w/601…800 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25 • 25 w/600 A Class J fuse
HD 350 50 • 18 w/601…700 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25 • 25 w/600 A Class J fuse
21G…E435 LD 500 50 • 30 w/601…1000 A Class L fuse
• 30 w/1000 A CB
• 100 w/800 A max Class L fuse • 30 w/800 A Class L fuse
ND 450 50 • 30 w/601…900 A Class L fuse
• 30 w/1000 A CB
• 100 w/800 A max Class L fuse • 30 w/800 A Class L fuse
HD 350 50 • 18 w/601…700 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25 • 25 w/600 A Class J fuse
21G…E460 LD 500 35 • 30 w/601…1000 A Class L fuse
• 30 w/1000 A CB
• 100 w/800 A max Class L fuse • 30 w/800 A Class L fuse
ND 500 50 • 30 w/601…1000 A Class L fuse
• 30 w/1000 A CB
• 100 w/800 A max Class L fuse • 30 w/800 A Class L fuse
HD 400 50 • 18 w/601…800 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25 • 25 w/600 A Class J fuse
21G…E510 LD 550 35 • 30 w/601…1100 A Class L fuse
• 30 w/1100 A CB
• 100 w/800 A max Class L fuse • 30 w/800 A Class L fuse
ND 500 35 • 30 w/601…1000 A Class L fuse
• 30 w/1000 A CB
• 100 w/800 A max Class L fuse • 30 w/800 A Class L fuse
HD 450 50 • 30 w/601…900 A Class L fuse
• 30 w/1000 A CB
• 100 w/800 A max Class L fuse • 30 w/800 A Class L fuse
21G…E595 LD 700 50
These options are not used with these drive ratings.
ND 600 50
HD 500 50
21G…E630 LD 800 50
ND 700 50
HD 600 50
21G…E760 LD 900 50
ND 800 50
HD 700 50
21G…E825 LD 950 50
These options are not used with these drive ratings.
ND 900 50
HD 750 50
21G…E900 LD 1000 65
ND 950 50
HD 800 50
21G…E980 LD 1100 65
ND 1000 65
HD 900 50
