266 Rockwell Automation Publication 750-IN001P-EN-P - April 2017
Chapter 5 I/O Wiring
Table 80 - TB2 Terminal Designations (Two Relay Outputs: 2R)
Table 81 - TB2 Terminal Designations (One Relay and Two Transistor Outputs: 1R2T)
(1) Digital Inputs are either 24Vs DC (2262C) or 115Vs AC (2262D) based on module catalog number. Verify applied voltage is correct
for I/O module.
(2) See HW Input PTC on page 268
for PTC data.
(3) Differential Isolation – External source must be maintained at less than 160V with respect to PE. Input provides high common
mode immunity.
(4) For CE compliance use shielded cable. Do not exceed cable length of 30 m (98.4 ft).
(5) I/O Module parameters also have a port designation.
ATTENTION: Risk of equipment damage exists. Verify that the correct
voltage is applied to the I/O Module digital inputs. See the I/O Module
catalog number to determine the voltage rating.
• 20-750-2262C-2R is rated 24V DC
• 20-750-2263C-1R2T is rated 24V DC
• 20-750-2262D-2R is rated 120V AC
Relay Out Terminal Name Description Related
Parameter
R0NO Relay 0 N.O. Relay normally open contact output:
240V AC, 24V DC, 2 A max
General-purpose (inductive)/resistive
Relay normally closed contact output:
240V AC, 24V DC, 2 A max
Only resistive
10, 100, 101,
105, 106
On port X
R0C Relay 0 Common
R0NC Relay 0 N.C.
R1NO Relay 1 N.O. 20, 110, 111,
115, 116
On port X
R1C Relay 1 Common
R1NC Relay 1 N.C.
Relay Out Terminal Name Description Related
Parameter
R0NO Relay 0 N.O. Relay normally open contact output:
240V AC, 24V DC, 2 A max
General-purpose (inductive)/resistive
Relay normally closed contact output:
240V AC, 24V DC, 2 A max
Only resistive
10, 100, 101,
105, 106
On port X
R0C Relay 0 Common
R0NC Relay 0 N.C.
T0 Transistor output 0 Transistor output
Rating: 24V DC = 1 A max
24V DC = 0.4 A Max for U.L.
applications
Resistive
20
On port X
TC Transistor output
common
T1 Transistor output 1 30
On port X
R0NO
R0C
R0NC
R1NO
R1C
R1NC
R0NO
R0C
R0NC
T0
TC
T1
