50
Rockwell Automation Publ
ication 750-IN001P-EN-P -
April 2017
Chapt
er 3
Lift and Moun
t the Drive
2.
At
tach lifti
ng h
ardw
are
to the
drive asse
mbly
.
F
ollow lift
in
g i
ns
t
ruct
ion
s a
nd pr
e
cau
tio
ns t
hat s
ta
rt on
pag
e
39
.
3.
L
ocate the fac
tor
y-assemb
led d
rive cabinets and cabinet options bay in
its fin
al p
osition.
4.
Remove and discard the seven M8 sealing screws from t
he right side of
the cabinet options bay
.
M8
13 mm
IP54, NEMA 12 Enclosu
re Rating Shown
49
51
