52
Rockwell Automation Publ
ication 750-IN001P-EN-P -
April 2017
Chapt
er 3
Lift and Moun
t the Drive
3.
Remove and discard the wir
ing bay in
ner panels th
at cover t
he ends of
the b
us b
ars
.
4.
Release the wiri
ng bay from t
he shipping sk
id.
The shippin
g angles on
the left side of the cabinet can be left in place to
ass
ist
with
a
li
g
nment in
step 6
. Remove the shippin
g angles af
ter
cabinets are alig
ne
d and joine
d.
M6 x 25
T30
Wi
ri
n
g
B
a
y
3/8 in.
9/16 in.
M8 x 16
13 mm
51
53
