80 Rockwell Automation Publication 750-IN001P-EN-P - April 2017
Chapter 3 Lift and Mount the Drive
Figure 45 - IP20, NEMA/UL Type 1, MCC Style Cabinet, Floor Mount Frame 9
(Enclosure Codes L, P, W)
M12 (1/2 in.) Property Class 8.8 anchor hardware is recommended
to fasten the drive cabinet through its internal mounting angle to the
foundation. Anchor bolts can be pre-located and embedded in the
foundation before instillation.
1200
(47.2)
800
(31.5)
240
(9.4)
1374
(54.1)
300
(11.8)
531
(20.9)
669
(26.3)
ø18.0
(0.71)
742
(29.2)
43
(1.7)
69
(2.7)
76
(3.0)
76
(3.0)
1
1
1
1
2
2
22
3
4
4
5
127
(5.0)
900
(35.4)
1131
(44.5)
440
(17.3)
270
(10.6)
440
(17.3)
2453
(96.6)
2300
(90.6)
1862
(73.3)
1464
(57.6)
292
(11.5)
292
(11.5)
440
(17.3)
440
(17.3)
127
(5.0)
76
(3.0)
127
(5.0)
6
No. Description
1Power wiring conduit plates.
2 Control wiring conduit plates.
3 Optional exhaust hood.
4 Disconnect switches (SW2). Common DC input drives.
5Optional HIM.
6 Recommended four-hole anchoring.
Bottom
Bottom
Top
