Lift and Mount the Drive Chapter 3
Figure 61 - IP54, NEMA 12, MCC Style Cabinet, Floor Mount Frame 8 (Enclosure Codes K and Y)
IP54, UL Type 12, MCC Style Cabinet, Floor Mount Frame 8 (Enclosure Code J)
M12 (1/2 in.) Property Class 8.8 anchor hardware is recommended
to fasten the drive cabinet through its internal mounting angle to the
foundation. Anchor bolts can be pre-located and embedded in the
foundation before instillation.
2477
(97.5)
2300
(90.6)
1464
(57.6)
800
(31.5)
1030
(40.6)
244
(9.6)
675
(26.6)
556
(21.9)
24
(1.0)
556
(21.9)
1703
(67.0)
480
(18.9)
78
(3.1)
1
2
3
4
2
127
(5.0)
1200
(47.2)
127
(5.0)
No. Description
1 Power wiring conduit plates.
2 Control wiring conduit plates.
3 Optional HIM.
4 Recommended four-hole anchoring.
Bottom
Top
800 mm (31.5 in.) Deep Drive with Cabinet
Options Bay
To Next Page
